LamiAd-340/500 Advertising Banner Fabric
- group name
- PVC Tarpaulin Sheet
- Min Order
- 1 piece
- brand name
- TAIMEI Tarpaulin Shade Fabric Manufacturer
- Nearest port for product export
- Qingdao Port, Shanghai Port
- Delivery clauses under the trade mode
- FOB, CFR, CIF, EXW
- Acceptable payment methods
- T/T, L/C, D/P D/A
- update time
- Mon, 23 Dec 2024 04:52:53 GMT
Paramtents
Life Time 1-2 year
Weight 340-500g/m²
Bese Fabric Polyester
Thickness 0.35-0.5mm
Roll Width (Max) 3.2/5.1m
Roll Length (Max) 20 - 800m
Surface Finishing PVC
Tensile Strength-Warp 350-650N/5cm
Tensile Strength-Weft 250-550N/5cm
Temp Resistance -30 to +70℃
Fire Retardent B1,B2 level
Treatment UV treated; Acrylic Lacquered
Printing Compatibility Printing Ready
Packging & Delivery
-
Min Order1 piece
Briefing
Designed for outdoor advertising, wall coverings, banners and other displays
Detailed
-
-
LamiAd-440/500 Advertising Banner Fabric
Recyclable and is designed for long term durability. Comes recommended for both outdoor and indoor displays.
This option for can used in Outdoor & Indoor banners, exhibitions, displays, backdrops, murals, signage, hoarding, standees, Flags, Boards, Banners, hoardings, front and backlit banners and Wallpapers.
| MATERIAL DESCRIPTION | |||||
|---|---|---|---|---|---|
| ITEM | UNIT | RESULT | TEST STANDARD | ||
| Weight (+/-3%) | g/m² | 340 | 440 | 500 | DIN EN ISO 2286-2 |
| Bese Fabric | Type | Polyester | Polyester | Polyester | DIN 60001 |
| Yarn | Denier | 200*300 | 300*500 | 500*500 | DIN EN ISO 2060 |
| Fabric Count | yarn/sq.inch | 18*12 | 18*12 | 9*9 | DIN EN 1049-2 |
| Thickness | mm | 0.35 | 0.44 | 0.5 | - |
| Roll Width (Max) | m | 3.2/5.1 | 3.2/5.1 | 3.2/5.1 | - |
| Roll Length (Max) | m | 20 - 800 | 20 - 800 | 20 - 800 | - |
| Surface Finishing | Material | PVC | PVC | PVC | - |
| Tensile Strength-Warp | N/5cm | 350 | 550 | 650 | DIN53354 |
| Tensile Strength-Weft | N/5cm | 250 | 450 | 550 | DIN53354 |
| Tear Strength-Warp | N/5cm | 120 | 160 | 200 | DIN53354 |
| Tear Strength--Weft | N/5cm | 80 | 140 | 220 | DIN53363 |
| Coating Adhesiion | N/5cm | 30 | 35 | 35 | DIN53363 |
| Temp Resistance | ℃ | -30 to +70 | -30 to +70 | -30 to +70 | DIN EN 1876-2 |
| Fire Retardent | B1,B2 level is optional upon request | ||||
| Treatment | UV treated; Acrylic Lacquered upon request. | ||||
| Color | 16 standard color, and can be customized. | ||||
| Printing Compatibility | Printing Ready | ||||
| Temp Resistance | Special treatment to use under -40℃ (optional) | ||||
| Note: The technical specifications contained herein are believed to be reliable, but no representations, guarantees or warranties of any kind are made regarding their accuracy or suitability of the material for particular applications. | |||||
Features:
- 100% Waterproof
- High Tenacity Strength
- Flexibility
- Crack Resistant
- Customized FR Standard
- REACH Regulations Standard
- Cadium Free
Colors Available:
-
Black
-
White
-
Red
-
Orange
-
Dark Green
-
Dark Red
-
Blue
-
Grey
-
Green
Applications:
-
Grain Covers & Cover
Protect grain from adverse weather conditions with grain covers -
Poultry House Curtain & Cover
One convenient and economy solution for the open the farm house -
Tree Watering Bag & Cover
Offer perfect solution to get the right amount of water to your plants
Downloads:
- LamiAd-340> Download
- LamiAd-440> Download
- LamiAd-500> Download
